model

HT-PT/C-2.1 for clustered blade

HT-PT/B-1.1 for wide-span blade

diameter mm

2000

Max. speed rpm

240

power kw

0.75

parameters

220V/1P, optional

Airflow throw distance and coverage area

For the clustered blade design, the airflow throw distance is ≥ 20 m. The airflow is concentrated along the axial direction within a central area approximately 5 meters in diameter.

For the wide-span blade design, the airflow covers an area of approximately 130° along the axial direction, with a throw distance of about 12 meters.

Overall weight

For the version with clustered capacity: ≤ 180 kg

For the version with wide span capacity: ≤ 160 kg

packing

Plywood box

Key configurations

Motor ：PMSM motor

Control panel：integrated VFD regulator

For clustered version: 5052H35 aluminum plate， thickness 2.5 mm punched process.

For wide-span version: Al-Pc Complex Blade

Technical features

A) Features a slim metal frame with a clean, transparent design.

B) Utilizes a unique dual-section structure: the upper section is a simple housing shell, while the lower section contains the power and control units. For shipping, multiple lower units can be stacked, and the upper housing shells can be layered. On-site assembly is straightforward. For export trade, shipping in knocked-down (KD) form can reduce per-unit freight costs by up to 50%.
